Indicator Devices and Cards for Vulcan Hammers

vulcanhammer.info

The indicator card, and the devices that produced them, have been around about as long as there have been steam engines.  The basic idea is simple: as the piston of the engine moved, a pressure indicator moved a needle and pen up and down on a paper (usually a rotating drum) and produced what’s called in thermodynamics a pV diagram, shown below.

indicator card An indicator card, taken from A Practical Treatise on the Steam Engine Indicator and Indicator Diagrams by Amice, edited and enlarged by W. Worby Beaumont, 1888. The area of the central region would indicate the energy output of the engine. The displacement is noted on the x-axis and the pressure on the y-axis. The straight lines over the region are probably a method of graphical integration, although even then (before the advent of CAD and numerical integration) a planimeter would be much easier.

The steam engine (or any…

View original post 229 more words
